Kirtas
Kabis II+
The
new Kirtas KABIS II+ system continues the
Kirtas tradition by providing the SmartCradle™
with new automatic book centering that increases
postprocessing productivity. The 110 degree
position is optimal for low stress, gentle
book positioning and Enhanced Page Separator
combine to separate pages, and the newest
SureTurn™ robotic arm with its vacuum
head will gently lift and turn the page.
Within
the vacuum head is our Page Edge Sensor technology
to detect multi-page or no-page lift conditions
and automatically take programmable corrective
action. The result is full book content integrity
and quality.The newest KABIS Manager Plus
software provides a simple user interface
to let you start digitizing quickly, and downloading
MARC or Dublin Core bibliographic information
to include with the book metadata, is simple
and easy from OCLC or your own database.
Product
Details
 |
Automatic
and Manual with speeds from 300-2,000
pages per hour |
|
Capture
images at true 325 x 325 ppi and 400 x
400 ppi, 24 bit color |
|
Patented
SmartCradle™ dynamic book handler,
with automatic centering |
|
Low-stress
support for rare, fragile books |
|
Robotics
that are gentler than the human hand |
|
SureTurn™
robotic arm gentle page turn ensuring
single page pick up and turn at a time |
|
Page
Edge Sensor ensures only one page is picked
up at a time |
|
KABIS
Manager Plus retrieve available Metadata
of MARC records, DublinCore, and MODS
files |
|
File
Output: JPEG or CR2 |
|
File
Output from LIMB: Color, grayscale, bitonal
TIFF, JPEG, JP2, PDF, PDF/A, BMP, etc.,
METS compliant |
|
File
Output with LIMB and OCR added: METS/ALTO
compliant, txt |
Technical
Specifications
|
CAPTURE
22.1
megapixel Canon Camera
325 ppi up to 11” x 14” (28
x 35.6cm)
400 ppi up to 12” x 8.50”
A4
|
|
PAGE
SIZE
11”
x 14” max. (28.0 x 35.6 cm) Automatic
4.5” x 7” min. (11.5 x 17.8
cm) Automatic
2”x 3” (50 x 75mm) Manual
|
|
PAPER
13–80
lb (49–300 gsm)
|
|
BINDING
Up
to 4” (10 cm) Automatic
|
|
DIMENSIONS
33”
x 32” x 47” (W x D x H)
84 x 82 x 121cm (W x D x H)
|
|
ACCURACY
Page
Edge Sensor, Enhanced Page Separator
|
|
WEIGHT
200lbs
(91 kg) approx.
|
|
POWER
Standard
110-240 VAC, 50/60 Hz
15 Amp Receptacle
|
|
CERTIFICATION
AN/NZS,
CE, CSA, EN, FCC, RoHS, UL,EAC
|
|
OUTPUT
Color,
grayscale, bitonal, TIF, JPG, JP2,
Searchable PDF with OCR, PDF/A with
OCR METS/ALTO,
DC, MODS, TXT with LIMB software
|
|
CONTROLLER
Quad
Core Xeon processors (min)
16 GB RAM
1 TB hard drive
Windows 7 64 bit Pro
22” flat screen
Mini keyboard & mouse
KABIS Manager Plus software
|
|
INCLUDED
Monitor
arm mount and keyboard tray
Enhanced Page Separator
Page Edge Sensor
Small book extension kit
Foot Pedal
KABIS Controller
KABIS Manager Plus software
Page Separator
Page Edge Sensor
|
|
OPTIONAL
Height-adjustable,
ergonomic table
LIMB™ Imaging Software
LIMB™ Desktop Software
LIMB™ Server Software
LIMB™ Workstation 13 computer
LIMB™ Server 13 Computer
ABBYY or IRIS OCR Modules
|
|
